China Made Turnstile Speed Gate

Item No.: TH-SG305
SG305 fits anywhere and harmonizes with the space unaffectedly. The exterior of whole of stainless steel is performing a smart form and being full of high-quality.
INQUIRY
Description

Speed Gate SG305 enjoys with simple-designed body harmonized with the space. Its exterior of glossy and beautiful hairline stainless steel finish is smart, elegant and sophisticated.

Each side of the body is unique designed  and it fits any floor and building. With acrylic flap-panels, an open area is born and an exaggeration is not given.

FEATURES Safety Universal Design With optional lower sensors and urethane flap-panels, children can also pass the gate safely. Also, the access indication is equipped with LED lights which is visible to the people of partial color blindness.

Tianhong has been already producing and exporting hundreds of  SG305 to more than 100 countires of the world market. All of them are deeply loved by our customers due to its excellent performance and highly-reliable working quality.


SG305 can be customized with OEM and ODM services. We also provide biometric devices, such as IC/ID card reader, fingerprint scanner, QR code scanner, face recognition camera, and so on.


Product Description


1. Configuration: Mechanism, Housing, Control board, Power supply
2. Power Consumption: Static state: single core 60W; dynamic state: single core 160W.
3. Power Input:AC220V
±10%,50HZ
4. Output:DC5V、DC12V、AC24V
5. Drive Mode: DC electric motor

6. Interface: one Rs 232 485 interface, two card reader signals (Passive), one fire alarm interface.
7. Overall Dimension: 1500L x 185W x 1020H (mm)
8. Following Speed: 35 people/minute in normal mode, 50 people/minute in fast mode

9. Service Life: Five millions continuous rotation
10. Operation Direction: Single/bi-directional

11. Working Environment: Indoor
12. Lane Width: 500mm-550mm
13. Opening angle:90
±5°
14. Noise:≤50dB
15. Opening and Closing Time: 1 second

16. Net Weight: Single core 70 KGS/set; double cores 100 KGS/set
